100瓦3KVAC隔离电压单输出3＂ X2＂ 微型尺寸交流对直流电源转换器(开放式)

在线询单

GB100A-Series

100瓦3KVAC隔离电压单输出3＂ X2＂ 微型尺寸交流对直流电源转换器(开放式)  100瓦3KVAC隔离电压单输出3＂ X2＂ 微型尺寸交流对直流电源转换器(开放式)

GB100A系列是100瓦的单输出、开放式交流对直流电源转换器，通用输入电压90~264VAC，尺寸仅3"x2"，3KVac隔离电压，具备短路、过载、过压和过温保护功能，效率最高可达到94%(标准值)。

元册科技的交流对直流电源转换器产品皆符合RoHS认证，并且可以接受产品客制化。

功能&特点

  • 通用输入电压90~264VAC。
  • 效率高达94%(标准值)。
  • 短路/过载/过压/过温保护。
  • 内置主动式PFC功能。
  • 3" x 2" 微型尺寸。
  • 空载功耗<0.3W。
  • 产品保固2年。

产品应用

  • 电脑设备。
  • AC主电源系统。
  • 工业控制。
  • 消防系统。
  • 电子仪器。


除非有特别定义，否则额定输入电压和额定输出电流值一般指在常温25度环境下

Part Number Output Voltage Output Current Ripple & Noise Efficiency Output Power(W)
V MAX mVp-p(Max) (note) %(TYP) Rated
GB100A-S12 12 8.3A 100 91 100
GB100A-S15 15 6.6A 120 92 100
GB100A-S24 24 4.16A 150 93 100
GB100A-S27 27 3.7A 150 94 100
GB100A-S48 48 2.08A 200 93.5 100

输入规格

Parameters Conditions Min Typ Max Units
Rated Input Voltage Io nom   100 ~ 240   Vac
Voltage Range Io nom 90   264 Vac
Io nom 127   370 Vdc
Frequency   47 50/60 63 Hz
Inrush Current At 115Vac     30 A
At 230Vac     60 A
Input Over-Current Protection VDE/UL/CCC FUSE 3.15A/250V
Power Factor PF> 0.93 / 230Vac PF> 0.98 / 115Vac at full load

输出规格

Parameters Conditions Min Typ Max Units
Output Voltage Accuracy Vi nom, Io nom     ± 2 %
Minimum Load Vi nom 0
Line Regulation Io nom, Vi min…Vi max   ± 0.5   %
Load Regulation Vi nom, Io min…Io nom   ±1.0   %
Protection Over Load Above 110% rated output power
Protection type: Hiccup mode, recovers automatically after fault condition is removed
Over Voltage 110%-150% rated output Voltage
Protection type: Shut off o/p voltage, re-power on to recover
Short circuit Protection type: Hiccup mode, recovers automatically after fault condition is removed
Over temperature Protection type: Shut off o/p voltage, re-power on to recover

Note:
Ripple & noise is measured by using 20 MHz bandwidth, measured with a 47uf paralleled with a high-frequency 0.47uf capacitor across each output by full load.

通用规格

Parameters Conditions Min Typ Max Units
MTBF MIL-HDBK-217F(25℃) 100,000     Hrs
Isolation Voltage Input To Output 3000V AC 5mA/5Secs
Input To Ground 2000V AC 5mA/5Secs
Output To Ground 500V AC 5mA/5Secs
Size   76.2x50.8x27.0MAX mm
Weight     125   g
Operating Temperature With Derating -20   +70 °C
Storage Temperature   -45   +85 °C
